WS-SCL-1
WS
8421219990
A reverse osmosis (RO) system is a pressurized filtration unit that employs a semi-permeable membrane to eliminate dissolved salts and contaminants. Functioning opposite to natural osmotic processes, it is termed "reverse osmosis." This method exploits variations in osmotic pressure among different substances to separate, purify, or concentrate liquids efficiently.
RO systems are capable of filtering out more than 97% of dissolved salts, as well as over 99% of colloids, bacteria, fine particles, and organic compounds. They are recognized for their energy efficiency, eco-friendliness, simple design, consistent high-quality output, and user-friendly maintenance.
--Specific parameters
| Model | Capacity | Motor power | Size(mm) | Weight |
| WS-SCL-1 | 1000L/H | 2.2KW | 2400×1400×1800 | 250KG |
| WS-SCL-2 | 2000L/H | 2.5KW | 2600x1400x1800 | 350kg |
| WS-SCL-3 | 3000L/H | 4.5KW | 2800×1400×1800 | 450kg |
| WS-SCL-5 | 5000L/H | 6.5KW | 3500×2000×1800 | 550kg |
| WS-SCL-10 | 10000L/H | 12KW | 4000×2000×1850 | 750kg |
| WS-SCL-15 | 15000L/H | 15KW | 4500×2000×1850 | 930kg |
| WS-SCL-20 | 20000L/H | 18KW | 5500X2400X2000 | 1200kg |
1. Electronics Manufacturing: Provides ultra-pure water for producing components such as silicon wafers, integrated circuits, display panels, and glass substrates.
2. Pharmaceutical Applications: Supplies high-purity water for medication production, dialysis fluids, laboratory analysis, and infusion solutions.
3. Industrial Boiler Feed Water: Delivers softened and demineralized water for power plants, heating systems, and factory boilers.
4. Beverage Production: Used in creating purified, mineral, and distilled water, as well as in brewing beer, blending spirits, and non-alcoholic drink manufacturing.
5. Commercial & Residential Water Systems: Ensures clean water supply for hotels, housing communities, public facilities, and swimming pools.
6. Chemical & Cosmetic Industries: Supplies purified process water for cooling, chemical synthesis, fertilizer production, and cosmetics manufacturing.
--RO water treatment process
Original water pump → quartz sand filter tank → activated carbon filter tank → ion exchange → precision filter tank→
RO unit → pure water tank
--Our Certification
--FAQ
Q: Are you a manufacturer or a trading company?
A: We are a professional manufacturer.
Q: Where is your factory located in Shanghai?
A: Our facility is based in Fengxian District, Shanghai.
Q: Do you supply part of the equipment or the whole project?
A: We specialize in turnkey solutions, delivering the complete production line.
Q: Do you provide drawings and plant design?
A: Yes, we provide comprehensive design and engineering drawings.
Q: Do you have an installation team?
A: Yes, we have a professional team for overseas installation and commissioning.
Q: How long is the equipment warranty?
A: We offer a standard one-year warranty.
Q: Can you provide product certificates?
A: Certainly. All our Weishu equipment comes with full certifications.
